Delta Alucobond Composite PanelDor

The Aluminum PanelDor is the benchmark in modern contemporary design. Using lightweight composite aluminium in a wide range of colours and finishes to achieve an ultra-modern look for your home.

Door Data

  • Door Height *

    Delta PanelDors overlap the opening by 10mm in height, therefore the door height should be 10mm higher than the opening width. Size entered in millimetres (mm)Min: 1800Max: 5150

  • Door Width *

    Delta PanelDors overlap the opening by 60mm in width, therefore the door width should be 60mm wider than the opening width. Size entered in millimetres (mm)Min: 1800Max: 8000

  • Lifting System: *

    If unknown, list "Standard Headroom"

  • Composite panel edge folding for coastal environments

Product total

Options total

Grand total

SKU: N/A Category:

Description

DESCRIPTION:

The Aluminum PanelDor is manufactured from our standard 38mm frame (powder coated black as standard), comprised of purpose-designed extruded aluminium rails & extruded aluminium stiles. Composite material is face-fixed to the frame, using industrial adhesive.

SPECIFICATIONS:

  • Type: Sectional Overhead Door
  • Tech Description: The PanelDor garage door is made up of a
    number of rigid sections that are hinged together and move vertically in the opening, then horizontally along the ceiling, guided by tracks and counterbalanced with springs.
  • Model: DALU
  • Description: Extruded Aluminium Frame With Face Fixed Composite Aluminium
  • Construction: 6063-T5 Extruded Aluminium
  • Frame Finish: Powder Coat Satin Black (Std) or Alternate
    Powder Coat Colour (Optional)
  • Panelling Options: Alucobond Plus Composite Sheet
  • Designs: 10mm Shadowlines (Std) or But Joint (Optional)
  • Windows: Yes – Acrylic Windows
  • Max Height: 5150mm
  • Max Width: 8000mm
