Description
FAAC Die Cast Rear Fork Kit – 4900645
Genuine FAAC replacement die cast rear fork kit for compatible FAAC 400, 402 and 422 hydraulic swing gate operators.
The rear fork connects the rear of the hydraulic operator to the mounting bracket installed on the gate post or pillar, providing the pivoting connection required as the gate opens and closes.
Ideal for replacing a worn, damaged or broken rear mounting fork on an existing FAAC hydraulic swing gate operator.
FAAC Part Number: 4900645
⚙️ Rear Operator Mounting Point
The rear fork is fitted to the back of the hydraulic operator and connects it to the rear mounting bracket.
This connection provides a secure mounting point while allowing the operator to pivot as the geometry of the swing gate changes throughout the opening and closing cycle.
🔩 Complete Rear Fork Kit
The 4900645 is supplied as a replacement kit rather than just the individual fork.
The kit includes:
- 1 × Aluminium Die Cast Rear Fork
- 1 × Short Fixing Pin
- 1 × Long Fixing Pin
- 2 × Retaining Nuts
This provides the primary components required to replace the rear fork assembly.
🏗️ Die Cast Aluminium Construction
The replacement fork is manufactured from aluminium and designed specifically for the rear mounting arrangement used on compatible FAAC hydraulic operators.
FAAC parts documentation identifies the original component as the Die-Cast Rear Fork.
🔄 Allows Operator Pivoting
A swing gate operator does not remain at a fixed angle while the gate moves.
As the gate opens and closes, the operator changes angle relative to the gate post and gate leaf.
The rear fork provides the pivoting connection required between the operator and its fixed rear mounting bracket, allowing this movement while keeping the operator securely mounted.
🔧 Replacement Spare Part
Replacement may be required where the existing rear fork has:
- Become worn
- Sustained physical damage
- Developed excessive movement
- Been damaged around the pivot points
- Become distorted
- Been damaged during removal or servicing
The rear mounting bracket and associated mounting points should also be inspected whenever the rear fork is replaced.
🧰 Genuine FAAC Spare Part
Part number 4900645 is the genuine FAAC replacement Rear Fork Kit listed within the spare-parts documentation for compatible FAAC hydraulic swing gate operators.
Using the correct rear fork maintains the original mounting geometry and pivot arrangement of the operator.
Key Features
- Genuine FAAC spare part
- FAAC Part Number: 4900645
- Die cast rear fork kit
- Aluminium rear fork
- Rear operator mounting component
- Provides pivoting connection at rear of operator
- Fixing pins included
- Retaining nuts included
- Suits compatible FAAC 400 operators
- Suits compatible FAAC 402 operators
- Suits compatible FAAC 422 operators
- Ideal for repairs and refurbishment of FAAC hydraulic swing gate operators
Specifications
- Manufacturer: FAAC
- Brand: FAAC
- Product: Die Cast Rear Fork Kit
- Part Number: 4900645
- Product Type: Rear Operator Mounting Fork
- Material: Aluminium
- Application: Hydraulic Swing Gate Automation
- Mounting Position: Rear of Operator
- FAAC 400 Compatible: Yes
- FAAC 402 Compatible: Yes
- FAAC 422 Compatible: Yes
- EAN: 8055195015768
Compatibility
Compatible with applicable versions of:
- FAAC 400 Hydraulic Swing Gate Operator
- FAAC 402 Hydraulic Swing Gate Operator
- FAAC 422 Hydraulic Swing Gate Operator
The 4900645 Rear Fork Kit appears within FAAC spare-parts documentation for all three hydraulic operator families.
📦 What’s Included
Supplied as:
- 1 × Die Cast Aluminium Rear Fork
- 1 × Short Fixing Pin
- 1 × Long Fixing Pin
- 2 × Retaining Nuts
FAAC Part Number: 4900645
The fixed rear mounting bracket and mounting plate are separate components and are not included unless specifically stated.
⚠️ Please Note
This listing is for the FAAC 4900645 Die Cast Rear Fork Kit.
The rear mounting bracket fitted to the gate post or pillar is a separate component and is not included unless specifically stated.
When replacing a damaged or heavily worn rear fork, inspect the fixing pins, rear mounting bracket and operator mounting points for corresponding wear or damage.
Correct rear mounting geometry is critical to the operation of a swing gate motor. The operator mounting dimensions should not be altered simply when replacing the rear fork.
The gate and operator should be safely supported before removing any mounting pins or brackets.
If you are unsure whether the 4900645 Die Cast Rear Fork Kit suits your FAAC swing gate operator, use our compatibility checker or contact our Technical Support team on 1300 733 066.
